Alumina Ceramic Porous Disc Filter for Chemical Industry

  • Material:95-99%,Al2O3
  • Colour:White,Ivory,Pink,Dark.
  • OD: 11.5mm---45mm
Inquire
Product Description

Features & Benefits

  • High temperature resistance
  • High strength and hardness
  • Wear and corrosion resistance
  • Electrical insulation
  • Chemical inertness
  • Biocompatibility

Markets & Applications

  • Aerospace and defense
  • Automotive and transportation
  • Electronics and semiconductor
  • Medical and dental
  • Energy and power generation
  • Industrial and manufacturing

Specification

Dimension Outer dia. mm Inner dia.mm Length mm Remark
Item
Thermocouple protection tube 7-170 1-110 10-2500 If you need others,we can customize for you.
Insulated tube Single hole 2-530 1-500 10-5200
(inner core) Double holes 1-10 0.4-2 10-2500
Four-Nine holes 1-10 0.5-2 10-2500



Parameters of Alumina Ceramic

Item Test Condition 78-82% Al2O3 95% Al2O3 99% Al2O3 99.5% Al2O3
Physical properties Density g/m³      >2.9 >3.6 3.89 3.96
Moisture absorption %   5-7 0 0 0
Mechanical properties ROHS Hardness     60-70 ≥85 ≥89 ≥89
Flexural strength psiX103 20℃   358 550 550
Compressive strength psiX103 20℃   2068(300) 2600(377) 2600(377)
Fracture toughness Mpa.m3/2 K(l c)   4.3 5.6 6
Thermal properties Maximum use temperature   1350 1450 1600 1650
Thermal expansion coefficient 1X10-6/℃ (25-1000℃) 6.1-6.6 7.6 7.9 8.2
Thermal shock resistance Tc very good 250 200 200
Thermal conductivity w/mok 20℃   16 30 30.4
Electrical properties Volume resistivity Ohm/cm2 100℃ >1013 >1013 >1014 >1014
Dielectric breakdown strength KV/mm   8.7(220) 8.7(220) 8.7(220) 8.7(220)
Dielectric constant (E) 1MHz25℃ 9 9 9.7 9.7
Dielectric constant (100MHz) (E) 9.5
