Alumina Ceramic Roller

Alumina ceramic rollers are cylindrical-shaped components made of high-purity alumina ceramic material that is used in a variety of industrial applications. These rollers are designed to be highly wear-resistant and can withstand high temperatures and harsh environments. They are often used in applications such as ceramic manufacturing, glass processing, and steel production.

Inquire
Product Description

Features & Benefits

  • High wear resistance: Alumina ceramic rollers are extremely durable and resistant to wear, making them ideal for use in applications where abrasive materials are present.
  • High-temperature resistance: Alumina ceramic rollers can withstand high temperatures, making them suitable for use in high-temperature industrial processes.
  • Chemical resistance: Alumina ceramic rollers are resistant to most chemicals, acids, and alkalis, making them ideal for use in harsh environments.
  • Dimensional stability: Alumina ceramic rollers have excellent dimensional stability and are resistant to deformation, even under heavy loads.
  • Low friction: Alumina ceramic rollers have a low coefficient of friction, making them ideal for use in applications where low friction is desired.

Markets & Applications

  • Ceramic manufacturing: Alumina ceramic rollers are used in the production of ceramic products, such as tiles, pottery, and sanitary ware.
  • Glass processing: Alumina ceramic rollers are used in glass processing applications, such as the production of flat glass and glass containers.
  • Steel production: Alumina ceramic rollers are used in the production of steel products, such as wire, rod, and sheet.
  • Other industrial applications: Alumina ceramic rollers are also used in a variety of other industrial applications, such as in the production of electronic components, aerospace components, and medical implants.

Specification

Dimension Outer dia. mm Inner dia.mm Length mm Remark
Item
Thermocouple protection tube 7-170 1-110 10-2500 If you need others,we can customize for you.
Insulated tube Single hole 2-530 1-500 10-5200
(inner core) Double holes 1-10 0.4-2 10-2500
Four-Nine holes 1-10 0.5-2 10-2500



Parameters of Alumina Ceramic

Item Test Condition 78-82% Al2O3 95% Al2O3 99% Al2O3 99.5% Al2O3
Physical properties Density g/m³      >2.9 >3.6 3.89 3.96
Moisture absorption %   5-7 0 0 0
Mechanical properties ROHS Hardness     60-70 ≥85 ≥89 ≥89
Flexural strength psiX103 20℃   358 550 550
Compressive strength psiX103 20℃   2068(300) 2600(377) 2600(377)
Fracture toughness Mpa.m3/2 K(l c)   4.3 5.6 6
Thermal properties Maximum use temperature   1350 1450 1600 1650
Thermal expansion coefficient 1X10-6/℃ (25-1000℃) 6.1-6.6 7.6 7.9 8.2
Thermal shock resistance Tc very good 250 200 200
Thermal conductivity w/mok 20℃   16 30 30.4
Electrical properties Volume resistivity Ohm/cm2 100℃ >1013 >1013 >1014 >1014
Dielectric breakdown strength KV/mm   8.7(220) 8.7(220) 8.7(220) 8.7(220)
Dielectric constant (E) 1MHz25℃ 9 9 9.7 9.7
Dielectric constant (100MHz) (E) 9.5
